OVERVIEW

PRODUCT DESCRIPTION

CM series are non-self-priming light horizontal multistage centrifugal pump with long shaft motor,compact structure,smaller size, axial inlet and radial outlet. Most parts adopt stamping technology.

It’s energy saving,environmental friendly, with beautiful appearance,light weight,low noise,convenient installation and maintenance, and high reliability.


FEATURES AND ADVANTAGES

CM series is a non-self-priming light horizontal multi-stage centrifugal pump with extended shaft electricity.

The machine has a compact structure.

Most of the parts of the product adopt stamping process, which has the advantages of energy saving, low limit, environmental protection and appearance.

It has the characteristics of beautiful appearance, light weight, installation, push and protection, high reliability and so on.


MOTOR

TEFC motor-2 pole

Protection class: IP55

Insulation class:F

Standard voltage :1×220V

     3×220/380V


PERFORMANCE


DOWNLOAD

PRODUCTS AND MARKETS

CNP, a green water expert beside you.

TECHNICAL DATA

Flow：0.5m³/h～7m³/h

Head：7.5m～56m

Liquid temperature range：-15℃~+105℃

Max. ambient temperature: 40℃

Max.working pressure: 10bar

APPLICATIONS

HVAC

Cooling system

Industrial cleaning

Water treatment

Aquaculture

Fertilization and metering system

Other specific applications
